Description
Round cables and PVC Trunking
Anchor fixings for wire etc.
Cables with an overall diameter between 4-6mm
LINIAN FIRECLIP™, Red, 9-11mm, Double, 1LCR9112
- Colour: Red
- Cable type: Double (two cables)
- Size: For cables with an overall diameter between 9-11mm
- Equivalent cleat size: 5(x2) (CC5x2)
- Recommended spacing: 300mm
- Hole diameter: 6mm*
- Hole depth: 30mm
- Supports a max tensile load of 24kg
Equip yourself with an extraordinary upgrade in cable clip design that delivers major benefits in efficiency, safety and value for money. The LINIAN FireClip™ is a single-component, 18th Edition-compliant, fire-rated fixing. Perfected through years of development, this exceptional innovation looks simple – and it is.
To install, drill a hole, slide the clip over the cable or conduit, and push it in! No plugs, screws, washers, cleats or nail-in clips are needed.
Expertly designed to save time, money and lives, this remarkable evolution of a vital building component can help you make every job faster, safer, simpler and tidier!
Suitable for:
- Round cables and PVC Trunking
- Anchor fixings for wire etc.
Features:
- 18th Edition Compliant
- Corrosion Resistant & UV Stable
- Fire-resistant >1200°C
- BSEN 50200 120 minutes fire time
- DIN 4102-12 DIN 90 minutes fire time
- CE & CA Certified
- Single-component design
- No plugs, screws or washers needed
- Made in Britain
- NOW IN SUSTAINABLE PACKAGING
LINIAN FireClips™ are available in a range of colours including Red, Black, and White (and more) to suit single or double cables with diameters from 4mm – 14mm.
*+/- 0.5mm. Varies for best fixing according to the substrate.
Technical Specification:
Weight: 0.247g
Cable Dimension: 9-11mm (CC5x2)
Colour: Red
Pack Size: Pack of 100
